EU fire-resistant cable

Essential information

Brand: LLT
Place of origin: Shenzhen, China
Specification: 100M / 500m per roll
Packaging method: roll / wooden shaft / carton / pallet
Place of shipment: Shenzhen
Mode of transportation: Sea / land / air
Payment method:T / T, L / C, D / P
Starting quantity: 5000m
Daily production: 1000000m
Other services:OEM/ODM

Products

Total 0 Page 0 Records

Product Details

Product name: EU fire-resistant cable
Product model: EU fire-resistant cable
Product category: Fire alarm cable Fire cable
Executive standards: EN50575 , CPR (Aca,B1ca,B2ca,Cca,Dca,Eca,Fca),EN50399
Product application: Suitable for wiring fire control panels, detectors, speakers, pull panels, strobes, and on-site modules in fire alarm systems
Rated voltage: 250/250V or 450/750V
Rated temperature: -25 ℃ -110 ℃

Technical Parameters:

No.of cores×Nominal cross section	(mm) Copper Wire Diameter	（mm） Nominal thickness of insulation	（mm） Nominal thickness of sheath	(mm) Approx overall diameter	Max. Conductor Resistance at 20℃
No.of cores×Nominal cross section	(mm) Copper Wire Diameter	（mm） Nominal thickness of insulation	（mm） Nominal thickness of sheath	(mm) Approx overall diameter	BARE COPPER	Tinned Copper
2×0.75	7×0.37	0.6	0.9	6.5×4.1	25.3	26.0
2×1.0	7×0.42	0.6	0.9	7.2×4.3	21.2	21.6
2×1.5	7×0.52	0.6	0.9	7.2×4.5	13.6	13.8
2×2.5	7×0.67	0.7	1.0	8.8×5.4	7.41	7.56

The layout does not display all specifications. Please contact the business manager for different cable specifications, which can be customized

Certificates

Packaging information

Normally the cables are packed by drum,carton and put on the pallet and other customized packing are available as per international standard.

Factory information

Super production capacity-more than 100 sets of automated production equipment, 24-hour production system, daily production capacity of 1,000,000 meters of cables
Strict quality inspection procedures-material inspection before production, index inspection during production, general quality inspection after production, packaging inspection
Complete certificate guarantee-IS09001 certification, IS014001 certification, CCC certification, CE certification, UL certification, LPCB certification, VDE certification, etc., so you can purchase with confidence
Efficient packaging and transportation-machineized packaging, fast and clean. Port city, direct air and sea transportation, fast delivery
7*24 hours after-sales service-professionals provide you with services and consultations around the clock
We can also provide OEM and ODM services
